| Difficulty | Intermediate |
|---|---|
| Included | 45 PDF drawings + 160-page builder’s manual |
| Format | PDF (instant download) |
| File Size | 18 MB ZIP |
Build a KITFOX Replica from Plans – The “Raven”
The Raven is very similar in construction, performance, appearance and dimensions to the Kitfox and the Avid Flyer. It is a high wing 2 seater, of tube and fabric construction. It has simple fore and aft aluminium tube wing spars and the wings can be folded back for trailering or to save hangar space.
45 Drawings + 160-Page Builder’s Manual
There are 45 detail PDF File drawings. Included is a comprehensive 160+ page PDF Builder’s Manual, which has building instructions and a complete hardware and material list.
Performance & Specifications
- Empty weight: 440 lbs with a 50hp Rotax 503 (could be equipped with engines up to 80 hp)
- Gross weight: 850 lbs
- Cruise speed: 75 mph
- Take off and approach: 55 mph
- Stall: 45 mph
- Take off roll: 275 ft with 2 on board
- Landing roll: 275 feet
- Wing Span: 30 ft
- Wing area: 120 sq ft
- Length: 18 ft
- Cabin width: 36" (can be widened to 39" or as builder choses)
Tube and Fabric Construction – Wings Fold for Trailering
The airframe uses steel tube with fabric covering and aluminium tube wing spars. The folding wing design means you don’t need a full-width hangar – many builders tow their Raven to the airfield on a custom trailer. Suitable for first-time aircraft builders with basic metalworking and fabric covering skills.
File Size: 18mb ZIP file containing PDF. Instant download after purchase.
